PRODUCT DESCRIPTION
ADC12 Die-casting shell brings perfect heat dissipation, Simple&perfect appearance.Acrylic lens is optically designed with high transmittance. The light source cavity is sealed with ultra-white tempered glass.
APPLICATIONS
Roads, parking lots
Specification Features
1. Class l/Class II two models optional.
2. Surge Protection: 10kA/20kV
3. Use anti-UV acrylic lenses and tempered glass, with high lumen output.
4. IP rate IP65,lK09, saline fog test >500 hours
5. Input voltage:100-240 /277VAC,347-480VAC;operating Frequency:50/60Hz
6. Dimming options: DALl1-10V,0-10V,sectional dimming, light attenuation compensation.
7. Photo sensor options: 3 pin,5 pin,7 pin.
8. Tapered mounting arm, ensure the fixture centered after installation.
9. The gear box opened tool-free, maintenance using standard tools, automatic power off after opening, easy and safe.
| 3000-5700K | ||
| Catalog No. | Rated Wattage (W) | Delivered Lumens (Im) |
| LEDMZ9LD80W | 80+5% | 10400 |
| LEDMZ9LD100W | 100±5% | 13000 |
| LEDMZ9LD120W | 120±5% | 15000 |
| LEDMZ9LD150W | 150+5% | 19500 |
| LEDMZ9LD180W | 180±5% | 23400 |
| LEDMZ9LD200W | 200±5% | 26000 |
| LEDMZ9LD220W | 220±5% | 28600 |
| LEDMZ9LD240W | 240±5% | 31200 |
| LEDMZ9LD260W | 260±5% | 35100 |
| Item description | LEDMZ9LD80W001 | LEDMZ9LD100W001 | LEDMZ9LD120W001 | LEDMZ9LD150W001 | LEDMZ9LD180W001 | LEDMZ9LD200W001 | LEDMZ9LD220W001 | LEDMZ9LD240W001 | LEDMZ9LD260W001 | |
| Input voltage/frequency [VAC][HZ] |
100-277VAC 50/60HZ/347-480VAC | |||||||||
| Input current [A] | 0.27-0.9 | 0.33-1.1 | 0.4-1.33 | 0.5-1.67 | 0.6-2 | 0.67-2.22 | 0.73-2.44 | 0.8-2.67 | 0.89-2.9 | |
| Input watt [W] | 80±5% | 100±5% | 120±5% | 150±5% | 180±5% | 200±5% | 220±5% | 240±5% | 260±5% | |
| Power factor | >0.95@220V | >0.95@220V | >0.95@220V | >0.95@220V | >0.95@220V | >0.95@220V | >0.95@220V | >0.95@220V | >0.95@220V | |
| Voltage [V] | 29 | 29 | 29 | 29 | 29 | 29 | 29 | 29 | 29 | |
| Current(reference) [A] | 2.48 | 3.14 | 3.72 | 4.72 | 5.65 | 6.28 | 6.9 | 7.59 | 8.28 | |
| Wattage(reference) [W] | 72±5% | 91±5% | 108±5% | 137±5% | 164±5% | 182±5% | 200±5% | 220±5% | 240±5% | |
| Luminous flux @5000K[LM] | 11200 | 14000 | 16800 | 21000 | 25200 | 28000 | 30800 | 33600 | 35100 | |
| Colour temperature [K] | 2700-6500k | |||||||||
| Colour rendering index [Ra] | 70 | |||||||||
| Beam angle [H,V] | IYPEn-M,IYPEII-S | |||||||||
| Average life [h] | 50000 | |||||||||
| Ambient temperture | -25℃-40℃ | |||||||||
| Chip | 3535 | |||||||||
| Material | ADC12 | |||||||||
| Storage enviranmei | -40°C-85°C RH10%-95% | |||||||||
| Net weight | 5.6Kg | 8.5KG | 10KG | |||||||
| Gross weight | 6.5Kg | 9.5KG | 11KG | |||||||
| Packing dimensions | 715*390*180 cm | 850*455*190mm | 970*530*190mm | |||||||
| Item description | LEDMZ9LD80W002 | LEDMZ9LD100W002 | LEDMZ9LD120W002 | LEDMZ9LD150W002 | LEDMZ9LD180W002 | LEDMZ9LD200W002 | LEDMZ9LD220W002 | LEDMZ9LD240W002 | |
| Inputvoltage/frequency [WAC][HZ] | 100-277VAC 50/60HZ/347-4B0VAC | ||||||||
| Input current [A] | 0.27-0.9 | 0.35-1.1 | 0.4-1.33 | 0.5-1.67 | 0.6-2 | 0.67-2.22 | 0.73-2.44 | 0.8-2.67 | |
| Input watt [W] | 80±5% | 100±5% | 120±5% | 150±5% | 180±5% | 200±5% | 220±5% | 240±5% | |
| Power factor | >0.95@220V | >0.95@220V | >0.95@220V | >0.95@220V | >0.95@220V | >0.95@220V | >0.95@220V | >0.95@220V | |
| Voltage [V] | 35 | 35 | 35 | 35 | 35 | 35 | 35 | 35 | |
| Current(reference) [A] | 2.06 | 2.6 | 3.09 | 3.91 | 4.69 | 52 | 5.71 | 6.29 | |
| Wattage(reference) [M] | 7215% | 91±5% | 108±5% | 137±5% | 164±5% | 182±5% | 200±5% | 220±5% | |
| Luminous flux @5000K [LM] |
10400 | 13000 | 15000 | 19500 | 23400 | 26000 | 28600 | 31200 | |
| Colour temperature [K] | 2700-6500k | ||||||||
| Colour rendering index [Ra] | 70 | ||||||||
| Beam angle [H, V] | IYPEn-M,IYPEII-S | ||||||||
| Average life [H] | 50000 | ||||||||
| Ambient temperture | -25℃-40℃ | ||||||||
| Chip | 3030 | ||||||||
| Material | ADC12 | ||||||||
| Storage environment | 40°C-85°C RH10%-95% | ||||||||
| Net weight | 5.6Kg | 8.5KG | 10KG | ||||||
| Gross weight | 6.5Kg | 9.5KG | 11KG | ||||||
| Packing dimensions | 715*390*180 cm | 850*455*190mm | 970*530*190mm | ||||||
