| Item description | LEDBG15W001B | LEDBG20W001B | LEDBG24W001B | LEDBG30W001B | LEDBG42W001B | LEDBG001- 60W30 | LEDBG001-80W40 | LEDBG001-100W44 | LEDBG001-120W55 I |
| Dimensions [mm] | 209*134*122(L*W*H) | 257*140*160(L*W*H) | 320*190*253(L*W* H) | 400*205*268(L*W*H) | |||||
| Input voltage [VAC] | 100-277VAC | ||||||||
| Input frequency [HZ] | 50/60 | ||||||||
| Input current [A] | 0.15 (100V) | 0.2 (100V) | 0.24 (100V) | 0.3 (100V) | 0.42 (100V) | 0.6 (100V) | 0.8 (100V) | 1.0(100V) | 1.2(100V) |
| Input wattage [W] | 15±5% | 20 ±5% | 24 ±5% | 30 ±5% | 42 ±5% | 60±5% | 80±5% | 100±5% | 120±5% |
| Power factor | >0.9 | >0.9 | >0.95 | >0.9 | >0.95 | ≥0.95@220V | |||
| Input voltage [V] | 18 | 24 | 30 | 36 | 27 | 30 | 30 | 33 | 33 |
| Input current [A] | 0.7 | 0.7 | 0.7 | 0.7 | 1.4 | 1.76 | 2.4 | 2.73 | 3.27 |
| Input wattage [w] | 10.5 ±5% | 12.6±5% | 16.8 ±5% | 21 ±5% | 37.8 ±5% | 53±5% | 72±5% | 90±5% | 109±5% |
| Power efficiency | ≥80% | ≥83% | ≥86% | ≥87% | ≥89% | ≥88% | ≥90% | ||
| Luminous flux [Lm] | 1350 | 1800 | 2160 | 2700 | 3780 | 7200 | 9600 | 1200014400 | |
| Colour temperature [K] | 2700-5700K | 3000-5700 | |||||||
| Colour rendering index [Ra] | ≥70 | ||||||||
| Lumen maintenance(2000h) [%] | L90>36000h | ||||||||
| Average life [h] | >54000 | ||||||||
| Net weight [Kg] | 1.65/ (set) | 1.65/ (set) | 1.65/ (set) | 2.46/ (set) | 2.46/ (set) | 5.2/set | 5.3/set | 7.0/set | 7.0/set |
| Gross weight [Kg] | 2.1/(set) | 2.1/(set) | 2.1/(set) | 3.1/(set) | 3.1/(set) | 6.0/set | 6.1/set | 8.0/set | 8.0/set |
| work environment | WET | ||||||||
| LED chip | 6 | 8 | 10 | 12 | 18 | ||||
| Ambient Temperature [℃] | -25°-45° | ||||||||
| Emergency wattage | 3~15W Options | ||||||||
| Emergency time | ≥ 90min | ||||||||
Years Of Experience
Universelite Co., Ltd. is a professional Good Heat Dissipation Small LED Wall Light Company and Good Heat Dissipation Small LED Wall Light Company
Universelite provides full ranges of HID, EDL and LED lightings, including Grow Lamp series, Street and Road Lighting series, Fishing Lamps, Aquarium Lighting series, Commercial Lighting series, EDL and LED products. The main products include High Pressure Sodium Lamp, High Pressure Mercury Lamp, Metal Halide Lamp, PAR lamp, elctrodeless lamp, EDL ballast and LED lamps, etc. The products are made of imported high quality materials with advanced equipments, cut-edge technologies and workmanship, and are of high lumen efficiency, long service life, energy saving and environmental friendly. The products have been selling successfully into Europe, North America, Australia, Southeast Asia, and other countries of the world.
Products have a variety of certification，
CCC, CE, FCC, CB, UL, CUL
ISO9001-2008/ISO14000
Focus on the field of lighting and serve the lighting industry at home and abroad.
The blue light in the Double Ended Hps Bulb 1000 Watt Plant Growth Lamp can directly activate chlorophyll a and chlorophyll b in plant cells. These two pigments are key c...
The die-cast shell of Led Grow Light is made of high-quality materials and has good heat dissipation performance. When the LED plant growth lamp works for a long time, th...
Due to its high thermal conductivity, aluminum PCB can quickly conduct away the heat generated by LED chips. LEDs generate a lot of heat when working. If the heat cannot ...
Due to their specific application scenarios, such as greenhouses and sheds, these environments are often accompanied by high humidity. Therefore, many LED plant lights ar...
