Description
Universelite series combines economical and security solution for outdoor perimeter and building facades. Designed look to deliver enhanced performance to outdoor wall-mounted lighting applications. Ideal use for warehouses, walkways, building entry ways, parking lots, retail exteriors and shopping malls.
Specification Features
Construction
Die Cast Aluminum Housing ensures reliability and durability.
Dark Bronze finish. IP65 Wet Location Rated.
Optical System
PC lens designed to reduce glare and improve over-all light distribution through precision formed LED optics.
Field-Adjustable CCT / Wattage
Wattage and Color Temp. can be adjusted in the field.
Certification
ETL Listed. All components have safety certification.
DLC Premium; FCC, IP65 rated
Photocell
Comes Standard with built-in dusk-to-dawn photocell.
Warranty
5 year Limited Warranty
Specification Sheet
|
Item No. |
Dimension |
Input |
Lumens |
Input |
Color |
CRI |
Average |
LED |
Driver |
|
LEDBG15W004 |
163*165*112 |
15W |
2100Lm |
AC100-277V 50/60Hz
|
3000K/ 4000K/ 5000K CCT
|
70 |
54000H |
2835 |
Universelite
|
|
LEDBG20W004 |
20W |
2700Lm |
|||||||
|
LEDBG30W004 |
30W |
3750Lm |
|||||||
|
LEDBG40W004 |
214*165*133 |
40W |
5520Lm |
||||||
|
LEDBG50W004 |
50W |
6600Lm |
|||||||
|
LEDBG60W004 |
60W |
7600Lm |
|||||||
|
LEDBG70W004 |
300*165*133 |
70W |
9450Lm |
||||||
|
LEDBG80W004 |
80W |
10400Lm |
|||||||
|
LEDBG90W004 |
90W |
11250Lm |
Dimension
Distribution Curve Flux
